Hi everbody.I have a doubt.I am doing a problem of filtering(fir)

in which we have to acquire our carrier precisely ..For that we have to do the
decimation, filtering(LPF) and down conversions(it is areal time application).TO
check the frequency I have to do fft at each stage ..NOw the doubt comes is
every time I do fft at each stage, the amlitude of fft peak decreases and it
becomes very low at the last stage ...WHAT CAN BE THE REASON?? The code is shown
below..

clc;

close all;

clear all;

fs43200;

fcE5e3;

no_samp=0:10000;

fb$00;

%acq_rang^3

%acq better=3/4/5Hz;

x=(2*pi*fc*no_samp/fs);

y=sin(x);

figure;

plot(abs(fft(y,8192)));

%%%%%%%%%%%%%%%

%mixing

%%%%%%%%%%%%%%%%%%%%

flo1@0e3;

fl_wav1=sin(2*pi*flo1*no_samp/fs);

figure;

plot(abs(fft(fl_wav1,8192)));

fl_wav2=cos(2*pi*flo1*no_samp/fs);

mx1=y.*fl_wav1;

figure;

plot(abs(fft(mx1,8192)));

mx2=y.*fl_wav2;

figure;

plot(abs(fft(mx2,8192)));

[n1,fo1,mo1,w1] = remezord( [0 60000], [1 0], [0.01 0.1], fs );

b1 = remez(n1,fo1,mo1,w1);

op1=conv(mx1,b1);

b2=hilbert(b1);

op2=conv(mx2,b2);

%%%%%%%%%%%%%%%%

%added signal

%%%%%%%%%%%%%%%%%

adop=op1+op2;

figure;

plot(abs(fft(adop,8192)));

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%decimate

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

decadimate(adop,4);

fs1=fs/4;

%%%%%%%%%%%%%%%%%%%%%%%%

%LPF

%%%%%%%%%%%%%%%%%%%%%%%

[n3,fo3,mo3,w3] = remezord( [0 65000], [1 0], [0.01 0.1], fs1 );

b3 = remez(n3,fo3,mo3,w3);

flop=conv(decad,b3);

figure;

plot(abs(fft(flop,8192)));

%%%%%%%%%%%%%%%

%squaring

%%%%%%%%%%%%%

sqop=flop.*flop;

figure;

plot(abs(fft(sqop,8192)));

%%%%%%%%%%%%%%%%%%%

%BPF

%%%%%%%%%%%%%%%%%%

[n4,fo4,mo4,w4] = remezord( [70000 90000 130000 150000], [0 1 0], [0.1 0.01
0.1], fs1 );

b4 = remez(n4,fo4,mo4,w4);

bpop=conv(sqop,b4);

figure;

plot(abs(fft(bpop,8192)));

%%%%%%%%%%%%%

%down conversion

%%%%%%%%%%%%%%

flo25e3;

flo2_wav=sin(2*pi*flo2*no_samp/fs1);

i=1;

for j=0:2500;

mxop(i)=bpop(i).*flo2_wav(i);

i=i+1;

end

figure;

plot(abs(fft(mxop,8192)));

%%%%%%%%%%%%%%%%%%

%LPF

%%%%%%%%%%%%%%

[n6,fo6,mo6,w6] = remezord( [0 10000], [1 0], [0.01 0.1], fs1 );

b6 = remez(n6,fo6,mo6,w6);

lpfop=conv(mxop,b6);

%%%%%%%%%%%%%

%decimation

%%%%%%%%%%%

decimate(lpfop,14);

fs2=fs1/14;

figure;

plot(abs(fft(dec,8192)));

%%%%%%%%%%%%%%%%%%%%%%

%LPF

%%%%%%%%%%%%%%%%%%%%%

[n5,fo5,mo5,w5] = remezord( [0 6000], [1 0], [0.01 0.1], fs2 );

b5 = remez(n5,fo5,mo5,w5);

output=conv(dec,b5);

figure;

plot(abs(fft(dec,8192)));

# doubt on amplitude of fft points

Started by ●April 8, 2009

Reply by ●April 9, 20092009-04-09

To respect the amplitude of the signal, you have to use:

for a signal NOT PERIODIC and simmetical time domain (-T/2 , T/2)

fftshift(fft(fftshift()))*dt

and for a asymmetric time domain

fftshift(fft())*dt

and the inverse:

ifftshift(ifft(ifftshift()))*fs

or

ifftshift(ifft(i))*fs

where dt = 1/fs and fs is the sampling frequency.

For a PERIODIC signal the formula become:

fftshift(fft(fftshift()))/Np

ifftshift(ifft(ifftshift()))*fs

where Np is the total number of points.

I hope this help

By

Daniele

On Tue, Apr 7, 2009 at 6:15 PM, mainraghav wrote:
